DBC 110 II
- Advanced Technical Capabilities: Designed to handle a wide range of parts from mid to large sizes, including die and mold components.
- Enhanced Productivity: Improved design features boost operational efficiency and productivity.
- User-Friendly Operation: Enhanced operating convenience ensures ease of use and increased efficiency for users.
Highlights
- Travels - X Axis Travel distance (mm): 2500
- Travels - Y Axis Travel distance (mm): 2000
- Travels - Z Axis Travel distance (mm): 1500
Compatible Control System
Series description
|
The DBC series, ranging from compact to super-size models, meets diverse customer needs with advanced technical capabilities. Designed for processing mid to large-size parts, including die and mold components, the series enhances productivity and adds value through improved design, operating convenience, and efficiency. |
Build Your Custom CNC Machine
Configure your perfect CNC milling machine or lathe by selecting from a range of customizable options. Some standard options have already been added to your machine and are pre-selected for your convenience. Once you've chosen your additional features, add them to the quote basket, and our sales team will get back to you with pricing details. Start building your ideal machine today!
Specifications
Travels
| Travels - X Axis Travel distance (mm) | 2500 |
|---|---|
| Travels - Y Axis Travel distance (mm) | 2000 |
| Travels - Z Axis Travel distance (mm) | 1500 |
Feed rates
| Feed rate - X Axis Rapid Traverse | 12 |
|---|---|
| Feed rate - Y Axis Rapid Traverse | 12 |
| Feed rate - Z Axis Rapid Traverse | 12 |
Table
| Table Length (mm) | 1800 |
|---|---|
| Table Width (mm) | 1400 |
| Max. Workpiece weight (kg) | 10000 |
| Max. Table weight (kg) | 10000 |
Workpiece capacity
| Max. Workpiece Diameter (mm) | 2250 |
|---|---|
| Max. Workpiece weight (kg) | 10000 |
Tool storage capacity
| Machining center - No. of tool station | 40/60/90 |
|---|
Capacity
| Table to spindle nose | 2050 |
|---|
Main spindle
| Tool Taper (ISO) | 50 |
|---|
Dimensions
| Length (mm) | 7630 |
|---|---|
| Height (mm) | 5070 |
| Width (mm) | 6990 |
| Weight (kg) | 36000 |
| Name | Download | File type | |
|---|---|---|---|
|
DBC series.pdf | 6915 KB |
Series delivery and installation
|
The project team manages the entire process, including delivery, installation, and commissioning of the machine, ensuring a seamless project flow. The project team ensures coordination and communication between the project's parties, including the customer, Duroc Machine Tool, and any third-party subcontractors. |
